Product description
- This is vertical bag forming filling packaging machine .The machine can reach the function of roller film holding ,pulling ,date coding ,bag forming ,product filling ,bag sealing and bag counting .Matching with different product it can use for packing different product like powder ,liquid ,sauce, granuler food and so on .
Features
- PLC control with stable, reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing, cutting, and finished in one operation
- Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable
- Servo control, high precision orientation, size more nicety
- External film releasing mechanism: simpler and easier installation of packing film
- Adjustment of bag deviation just needed to be control the touch screen. Operation is very simple
- Close down type mechanism, defending powder into inside of machine
Additional Info
- Bag Styles:Pillow Bag
- Bag Width:180 to 375mm
- Bag Length:100 to 500mm
- Product Characteristic:Granules, Powders, Liquids, Pastes
- Dosing System Compatible:Volumetric Cup , Piston Filler, Linear Scale , Multi-Head Scale, Auger Filler
- Running Motion:Intermittent
- Working Efficiency:5-40 bags/min
- Control By:PLC with HMI Touch Screen
- Date Coding Can Be:Hot Stamping Coder, Thermal Transfer Coder, Label Applicator
- Options Available:Perforation, Dust Absorb, Seal PE Film, SS Frame, SS & AL Construction, Nitrogen Flushing, Coffee Valve, Air Expeller, Heavy Bag, Heating & Mixing Hopper
- Power & Voltage:6 KW
- Compress Air:0 MPa 0.5 M3/min
- Dimensions:1750*1510*2100mm (68.9*59.4*82.7")
- Machine Weight:1000 KGS
Scope of application
This machine is suitable for automatic packaging of liquid of foods, medicine and chemicals,such as pesticide,shampoo,body foam bath lotion, facial cream, ingredient oil, fruit sauce,tomato ketchup and honey shower gel, skin lotion, toothpaste, cosmetic cream, fruit jam, edible oil, soy etc
FAQ
Normally we have some questions to customers,
1. What is you want to pack?
2. How many grams to pack?
3. What size of bag?
4. What is voltage and Hertz in your local?
